CYT8011TG 兼容可控硅調光LED線性恒流驅動芯片
產品描述：
CYT8011TG is a compatible SCR dimming linear constant current IC with adjustable output current, high constant-current accuraCy, simple application scheme, and it does not need too many components. The on-board IC driver is easy to assemble, reduces the material cost and improves the production efficiency. It has over-temperature protection function, safer and more reliable.
Support SCR dimming
The output current can be adjusted from 5 mA to 60 mA, with constant current accuracy.
Up to 3%
With over-temperature protection function
Chip design has no EMC problems
On-board IC driver with LED
Simple circuit and low cost.
Package form: ESOP8
