ICL1103 Single Channel HV Constant Current LED Driver
ICL1103 is a single channel high voltage linear constant current LED driver, which integrates 500V high voltage MOS. The output current can be set through an external resistor between 5mA and 60mA. IC...
ICL1103 is a single channel high voltage linear constant current LED driver, which integrates 500V high voltage MOS. The output current can be set through an external resistor between 5mA and 60mA. ICL1103 built-in linear type thermal protection function to effectively prevent damage to the system caused by high temperature. ICL1103 system has simple peripherals, flexible application, high reliability, small volume, low system BOM cost, adjustable packaging technology can be applied to all kinds of LED lamps.
550V/ 80mA HV NMOS integrated.
Constant current control technology.
System efficiency up to 93%.
Linear type thermal protection function.
NO EMI issue.
Various thermal protection trip temperature
available.
產品型號 驅動類型 輸入電壓 輸出電流 封裝方式 簡單描述 IML8673NL-TR AC-DC 110V/220V 180mA DFN2*2mm-6L 高壓性線 IML8674LL-TR AC-DC 110V/220V 180mA DFN3*3mm-10L 高壓性線 IML8676CL-TR AC-DC 110V/220V 180mA DFN3*3mm-8L 高壓性線 IML8684BP-ADJ-TR AC-DC 110V/220V 150mA SOT-89 高壓性線 IML8684NL-ADJ-TR AC-DC 110V/220V 150mA DFN2*2mm-6L 高壓性線 IML8685AE-TR Active 110V/220V 75mA TSOT23-3L 高壓性線 IML8686AK-TR AC-DC 110V/220V 250mA SOT-223 高壓性線 IML8686AP-TR AC-DC 110V/220V 150mA SOP89-3 高壓性線 IML8686APA-TR AC-DC 110V/220V 160mA SOP89-3 高壓性線 IML8686APB-TR AC-DC 110V/220V 110mA SOP89-3 高壓性線 IML8690NL-TR AC-DC 110V/220V 30W DFN2*2mm-6L 高壓性線 IML8693NE-TR AC-DC 110V/220V 30W TSOT23-6L 高壓性線 IML8691CL-TR Dimming 110V/220V / DFN3*3mm-8L PWM調光 IML8692CFA-TR AC-DC 110V/220V 25W SOP-8L 高壓性線 可控硅調光 IML3160AK MOS 600V 1.5A SOT-223 功率MOS管 AMC7140 DC-DC 5-80V 700mA TO-252-5L 線性降壓 ICL1701 DC-DC 5-75V 1.5A TO252-5L 線性降壓 ICL1702 DC-DC 5-40V 700mA ESop-8/TO252-5L 線性降壓 ICL9201 40V 50mA SOT-23 去頻閃IC ICL1101 AC-DC 110V/220V 7/14/21/28mA 70*70UM2 高壓性線 ICL1102 AC-DC 110V/220V 100mA SOT89/ESOP8/TO252 550V高壓性線恒流IC ICL1103 AC-DC 110V/220V 60mA SOT89/ESOP8/HSOP-7 550V高壓性線恒流IC ICL1104 AC-DC 110V/220V 100mA SOT89/ESOP8/TO252 650V高壓性線恒流IC ICL1202 AC-DC 110V/220V 100mA eSOP-8 智能調光線性恒流IC ICL1402/ICL1403 AC-DC 110V/220V 100mA*2 eSOP-8 雙通道高壓性線恒流IC ICNE2521DE/A/B AC-DC 110V/220V 100mA eSOP-8 高壓性線 ICNE2521DS/A/B AC-DC 110V/220V 100mA SOT-89-3 高壓性線 ICNE2521DT/A/B AC-DC 110V/220V 100mA TO-252-3L 高壓性線 ICNE2530DE AC-DC 110V/220V 100mA*2 eSOP-8 雙通道高壓性線恒流IC ICNE2531 AC-DC 110V/220V 100mA eSOP-8 可控硅調光高壓性線 ICL3101 AC-DC 85V-265V 150-220mA SOT-33-4L/SOP-7L 非隔離降壓恒流去VCC ICL3102 AC-DC 85V-265V 220-600mA SOP-7L/DIP-7L 非隔離降壓恒流去VCC ICL9101AP 開關調光 85V-265V 300mA SOP-8L 帶記憶雙通道調色溫 ICL9104AP 開關調光 85V-265V 280mA SOP-8L 帶記憶雙通道調色溫
